Maxi Twin Floor Lift by Arjo
The Maxi Twin Floor Lift by Arjo supports safe and efficient patient transfers while improving caregiver handling. Additionally, its open twin-mast design enhances stability and allows closer interaction between caregiver and patient.
Care environments require reliable lifting solutions. Therefore, the Maxi Twin helps reduce physical strain while improving safety during transfers.
**Sling Sold Separately
Maxi Twin Floor Lift features:
- Twin-mast design for improved stability and balance
- Open design for better access and patient legroom
- Large handholds for easier manoeuvrability
- Powered Dynamic Positioning System (PDPS)
- Supports single caregiver operation
- Designed for safe and precise patient transfers
Safe & Controlled Transfers
Caregivers can use the Maxi Twin to transfer patients with limited mobility. For example, it supports movement between:
- Bed
- Chair
- Wheelchair
Moreover, the PDPS system allows caregivers to reposition patients easily within the sling. As a result, it reduces manual handling and improves control.
Manoeuvrability
The twin-mast design distributes weight evenly. As a result, caregivers can move the lift more smoothly. In addition, the large handholds provide better control during transfers.
Powered Dynamic Positioning System (PDPS)
The PDPS improves positioning accuracy during transfers. Moreover, it reduces the need for manual adjustments. As a result, caregivers can reposition patients more easily and safely.
Range of Spreader Bars
Caregivers can choose from different loop spreader bar sizes or a 4-point spreader bar with PDPS. Therefore, the system adapts to various patient needs and transfer requirements.
Ergonomic Handling
The dual mast includes well-positioned handles. As a result, caregivers of different heights can operate the lift comfortably. In addition, this design helps reduce strain during use.
High-Friction Solution
The friction system helps stabilize the spreader bar. Therefore, it reduces unwanted swinging during transfers. As a result, it improves both safety and control.
Specifications
| Weight and dimensions | |
|---|---|
| Max safe working load kg | 182 kg |
| Max safe working load lb | 400 lbs |
| Lifter weight (with spreader bar and battery) kg | 58 kg |
| Lifter weight (with spreader bar and battery) lb | 126 lbs |
| Max lifting height mm | 1460 mm |
| Max lifting height in | 57,7 in |
| Min lifting height mm | 230 mm |
| Min lifting height in | 9,12 in |
| Lifting stroke mm | 1230 mm |
| Lifting stroke in | 48,5 in |
| Min total storage height mm | 1370 mm |
| Min total storage height in | 54 in |
| External width legs closed mm | 755 mm |
| External width legs closed in | 29,75 in |
| External width legs open mm | 54 in |
| External width legs open in | 1371 mm |
| Internal width leg closed mm | 630 mm |
| Internal width leg closed in | 24,9 in |
| Internal width leg open mm | 1231 mm |
| Internal width leg open in | 48,5 in |
| Leg clearance (floor to top of legs) - standard castors mm | 115 mm |
| Leg clearance (floor to top of legs) - standard castors in | 48,5 in |
| Leg clearance (floor to top of legs) – low castors mm | 4,7 in |
| Chassis clearance (floor to bottom of chassis) – standard & low castors mm | 31 mm |
| Chassis clearance (floor to bottom of chassis) – standard & low castors in | 1,2 in |
| Lifter length mm | 1298 mm |
| Lifter length in | 51,12 in |
| Turning diameter mm | 1440 mm |
| Turning diameter in | 56,6 in |
| Electrical | |
| Lifter protection class | IP24 |
| Hand control protection class | IPX7 |
| Battery | 24V, 2.5 Ah NiMH |
